How to Test PCB Board With a Multimeter

Thu February 29, 2024


As we all know, the root cause often comes down to a faulty component or poor connection on the PCB board when an electrical device malfunctions. Visual inspection is hard to reveal these issues, it is necessary to make comprehensive testing of the board necessary. Using a multimeter to systematically test a PCB board enables isolating faults and restoring normal functions.

Firstly,visual inspection checks soldering joints and connects for any integrity problems. If don’t find deviations, and then proceed to test all individual board components, like inductors, resistors, capacitors, diodes, ICs, etc. Comparing measured values against nominal specifications to identify defects.

Why is it important to test PCB with multimeter?

While PCB design software has simplified circuit creation, errors still occur even on basic boards. Layout issues missed by CAD,DRC and ERC inspection may exist. So human verification using a multimeter is essential for thoroughly testing a PCB board.

Engineers can overlook mistakes since the board seems correct when they review a familiar design. A fresh perspective is needed to meticulously test the PCB board with a multimeter. However, randomly probing points fails to cover all failure-prone areas.

Using a standardized checklist for common oversights vastly improves coverage. Additionally, chip vendors provide checklists for properly testing specific ICs. Combining these resources ensures comprehensive validation.

Step-by-Step Guide on Testing a PCB Board with a Multimeter

The design engineer completes the schematic and PCB layout in CAD, then assigns an inspector to verify the design. Firstly,the reviewer studies all materials to understand the board before testing.

A:The inspector copies the main checklist and documents results for each item:

1.Indicates passed test or item is not applicable.

2.Highlights in bold to mark obvious errors.

B:When testing the PCB board with a multimeter, key steps include:

1.Connect black probe to COM (common) socket and red probe to VΩ,if voltage is uncertain, set measurement limit to maximum as a precaution.

2.For DC voltage, switch multimeter to V mode. A negative reading indicates reversed polarity.

3.To measure capacitance, connect red probe to capacitor terminal after discharging electrolytics.

4.Select mA or A range based on expected currents,never exceed fused rating.

5.Additional functions like diode forward voltage, HFE, etc depend on meter capabilities.

6.Solder needle tips or attach alligator clips to easily connect probes to SMD parts or pads.

C:Advanced Techniques for Testing a PCB Board with a Multimeter

Here are some advanced multimeter techniques when testing a PCB board:

1.In-circuit resistance measurements – Power off before testing to avoid damage.

2.Isolate circuit sections with jumpers when troubleshooting complex boards.

3.Signal injection to simulate inputs and trace operation step-by-step.

4.Adjust test tolerances based on component specifications and application.

5.Log out-of-tolerance readings with possible causes for further diagnosis.

In summary, methodically testing a PCB board with a multimeter using checklists, following polarity and fused limits and employing advanced techniques will comprehensively validate design integrity and functionality before manufacturing. This prevents costly iterative corrections and ensures boards operate as intended when deployed.
